Corrugated Waveguide Termination

Corrugated resistors, also known as wire-wound power resistors or braking resistors, are industrial components specifically designed to **consume high-power electrical energy and enable rapid heat dissipation**. Their core function is to convert excess electrical energy in a circuit—particularly the regenerative energy generated during motor braking—into heat and release it, thereby **safeguarding main equipment such as frequency converters and servo systems**.

Send Inquiry

Product Introduction

It is an "energy discharge valve" born for high-energy consumption industrial scenarios. Through its physical design of corrugated vertical winding, it prioritizes ensuring exceptional heat dissipation capability, low inductance, and high reliability even under harsh conditions involving high parasitic inductance, significant mechanical stress, and extreme thermal cycling. Its high-temperature resistance is the foundation of its normal operation, not a flaw.

Product Images

Core Product Functions

Functional Dimension	Specific Manifestation	Core Problem Solved
Energy Handling	Convert regenerative electrical energy into thermal energy	Nowhere for the energy generated during motor braking to go
System Protection	Stabilize the DC bus voltage	Excessive voltage causing damage to the drive unit
Performance Assurance	Withstand instantaneous power surges & rapid heat dissipation	Short braking process and rapid heat accumulation
Reliable Operation	Low inductance, high temperature resistance, robust construction	Adapting to harsh electrical, thermal, and mechanical environments in industrial settings

Product Applications

Motor Rapid Braking	Protects drive equipment (frequency inverter/servo drive), prevents overvoltage of the DC bus, and enables fast, precise stopping.	Various machine tools, centrifuges, wire drawing machines, conveyor lines.
Potential Energy Load Lowering	Dissipates the continuous regenerative energy generated during load lowering, controls the lowering speed, and prevents system runaway.	Elevators, cranes, port machinery, mine hoists, oilfield nodding donkey units.
Industrial Testing & Discharge	Serves as a stable and reliable load or discharge circuit.	Power supply/frequency inverter test loads, capacitor discharge after equipment power-off.
